Vertiv Liebert PSI5-1100RT120N. UPS topology: Line-Interactive, Output power capacity: 1.1 kVA, Output power: 990 W. AC outlet types: NEMA 5-15R, Power plug: NEMA 5-15, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 4.5 min, Typical backup time at half load: 13.5 min. Form factor: Rackmount/Tower, Product color: Black, Rack capacity: 2U. Certification: Emissions FCC Part 15, Class B UL 497 B

Manufacturer: Vertiv

SKU: 7209486

Manufacturer part number: PSI5-1100RT120N

Vendor: Synnex

MSRP: $1,387.00

Price: $1,027.93

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

The flexible design of the Liebert® PSI5 allows the UPS to be tower (MT models), 1U rack mountable (1U models), or to be configured as a self-standing tower or to be rack-mounted within a 2U space (RT models). It is available from 750VA to 5000VA with both 120V or 208V models. The Liebert PSI5 UPS features an innovative advanced line-interactive design incorporating buck/boost Automatic Voltage Regulation (AVR) technology. This protects against utility voltage fluctuation by raising and lowering utility power to the level needed by the connected equipment. It also allows the UPS to prolong battery life by maximizing its time on utility power before going to battery. Not for sale in Vermont, Colorado, Washington.

Battery backup provides ample time for an orderly shutdown of connected equipment
Liebert® PSI5 UPS operates at a high 0.9 output power factor
Available network communications card provides remote monitoring
and power management capability — Local USB or SNMP via optional Vertiv™ Liebert® UNITY communication card
Liebert® PSI5 UPS is compliant with the Restriction of Hazardous Substances Directive (RoHS)
Rotatable LCD Display allows users to view real-time conditions, alarm notices, and runtime information
The standard Liebert® PSI5 UPS can accept external battery cabinets for long runtime applications

Overview
Specifications
Contact Us

Battery backup provides ample time for an orderly shutdown of connected equipment
Liebert® PSI5 UPS operates at a high 0.9 output power factor
Available network communications card provides remote monitoring
and power management capability — Local USB or SNMP via optional Vertiv™ Liebert® UNITY communication card
Liebert® PSI5 UPS is compliant with the Restriction of Hazardous Substances Directive (RoHS)
Rotatable LCD Display allows users to view real-time conditions, alarm notices, and runtime information
The standard Liebert® PSI5 UPS can accept external battery cabinets for long runtime applications

Products specifications

Attribute name	Attribute value
Width	17.2"
Depth	16.1"
Height	3.46"
Weight	65 lbs
Automatic Voltage Regulation (AVR)	Yes
Input Frequency	55/65 Hz
Cable Length	94.5"
Power factor	0.9
UPS topology	Line-Interactive
Technical details
Product color	Black
Packaging data
Package width	10.2"
Package depth	22.9"
Package height	21.7"
Package weight	83.6 lbs
Ports & interfaces
AC outlets quantity	6 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15
Design
Certification	Emissions FCC Part 15, Class B UL 497 B
Form factor	Rackmount/Tower
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	20 - 90 %
Power
Output power capacity	1.1 kVA
Features
Rack capacity	2U
Safety	UL 1778, c-UL-us Listed
Output power	990 W
Noise level	45 dB
Input operation voltage (min)	75 V
Input operation voltage (max)	146 V
Output operation voltage (min)	100 V
Output operation voltage (max)	125 V
Waveform	Pure sine
Surge protection	Yes
Battery
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at full load	4.5 min
Typical backup time at half load	13.5 min
